2.54mm Pin Header Connectors
Starting series for single-row, dual-row, straight, right-angle, SMT and through-hole PCB pin header RFQs.
View related productPin header orientation guide
Use a straight pin header when the mating connector plugs perpendicular to the PCB. Use a right-angle pin header when the cable, socket or second board must exit parallel to the PCB, usually because enclosure height or cable routing is limited.
| Item | Straight pin header | Right-angle pin header |
|---|---|---|
| Mating direction | Vertical to the PCB | Parallel to the PCB |
| Common mounting | DIP through-hole, vertical SMT or staggered SMT | Right-angle through-hole or horizontal SMT |
| Layout reason | Board stacking, jumper connection or top-side access | Side cable exit, low profile enclosure or edge connection |
| Mechanical review | Plastic height, stack height and tail length | Pin bend direction, board edge distance and mating clearance |
Related product series
Start from the matching series, then confirm pitch, rows, height, tail length, plating and drawing details by RFQ.
Starting series for single-row, dual-row, straight, right-angle, SMT and through-hole PCB pin header RFQs.
View related product
Use when the RFQ needs custom pin length, tail length, plastic height, plating, color or packing.
View related product
Mating socket series for board-to-board connections, module stacking and custom height review.
View related product
Browse Kirision pin headers, female headers, box headers, ejector headers and cable assembly options.
View related product2.54mm Pin Header Selection Guide | Pin Header Connectors | Send RFQ
