1.00mm Pin Header Connector
1.00mm pin header connector series for compact PCB board-to-board projects. Kirision can review single-row, dual-row, vertical DIP, right-angle and SMT options with tail length and plating confirmed by drawing.
Engineering CAD3D model available on request
Tell us the required pitch, rows, pin count and key dimensions.
Request 3D ModelAvailable specifications
- Product type
- Pin header connector
- Pitch
- 1.00mm
- Positions
- 1x1P to 2x50P options
- Rows
- Single-row and dual-row options
- Mounting style
- Vertical DIP, right-angle through-hole and SMT
- Catalog codes
- 0106 plus matching 1.00mm catalog rows
- Plastic height
- H1.0 / H1.5 options
- Custom options
- Pin count, tail length, plastic height and plating review
For a faster quote
- Share a drawing or product photo if available.
- Tell us the required pitch, pin count, mounting style and quantity.
- We will confirm dimensions and customization options with you.
Build your RFQ specification
Select the required connector format. This creates an RFQ specification for engineering review; it does not calculate an online price.
Choose pitch and rows to see the supported catalog pin range. Special multi-row or out-of-range designs require drawing review.
Available product variants5 catalog options
| Photo | Code | Professional English Name | Pitch | Rows / Positions | Mounting | Height | Drawing |
|---|---|---|---|---|---|---|---|
|
Series ref.
|
By drawing | 1.00mm Vertical DIP Pin Header Connector, Single Row, 1x1P to 1x50P | 1.00mm | Single row / 1x1P to 1x50P | Vertical DIP, Single Row | Customizable by drawing/sample | Request drawing |
|
Series ref.
|
By drawing | 1.00mm Right Angle Pin Header Connector, Single Row, 1x1P to 1x50P | 1.00mm | Single row / 1x1P to 1x50P | Right Angle Through-Hole, Single Row | Customizable by drawing/sample | Request drawing |
|
Series ref.
|
By drawing | 1.00mm Vertical DIP Pin Header Connector, Dual Row, 2x1P to 2x50P | 1.00mm | Dual row / 2x1P to 2x50P | Vertical DIP, Dual Row | Customizable by drawing/sample | Request drawing |
|
Series ref.
|
By drawing | 1.00mm Right Angle Pin Header Connector, Dual Row, 2x1P to 2x50P | 1.00mm | Dual row / 2x1P to 2x50P | Right Angle Through-Hole, Dual Row | Customizable by drawing/sample | Request drawing |
|
|
0106 | 1.00mm SMT Pin Header Connector, Dual Row, 2x1P to 2x50P | 1.00mm | Dual row / 2x1P to 2x50P | SMT | Customizable by drawing/sample | Request drawing |
Get 2D drawing or send RFQ
Request the drawing for a selected code, or send an RFQ for pricing and customization.
Related RFQ guides
Specification guides for this connector
Pin header tail length and plastic height RFQ guide
Use this when PCB thickness, solder tail and mating height are the main uncertainty.
Match pin header and female header before RFQ
Check mating height, insertion depth and row layout before sample confirmation.
2.54mm pin header selection guide
Compare rows, positions, mounting style, height, tail length and plating.
What 1.00mm pin header layouts can be reviewed?
Single-row and dual-row layouts can be reviewed, including vertical, right-angle and SMT structures.
What details matter most for 1.00mm RFQ?
Confirm pitch, rows, positions, mounting style, tail length, plastic height, plating and expected quantity.
