3.96mm Female Header Connector

3.96mm Female Header Connector series for PCB connector RFQ projects. Kirision can review Single Row, SMT, Single Row, Single row, 1x2P to 1x20P, plastic height or total height, tail length and plating by drawing or sample.

Get 2D drawing RFQ quote View Female Header series

3.96mm Female Header Connector, Single Row, 1x2P to 1x20P product photo by Kirision — Product example shown. Contact us for the required pin count and dimensions.

Available specifications

Product type: Female Header Connector
Pitch: 3.96mm
Rows: Single row
Positions: 1x2P to 1x20P
Mounting style: Single Row, SMT, Single Row
Catalog codes: 0139, By drawing
Height customization: Plastic height or total height can be customized by drawing/sample
OEM/ODM support: Pin count, height, tail length, housing and plating review

For a faster quote

Share a drawing or product photo if available.
Tell us the required pitch, pin count, mounting style and quantity.
We will confirm dimensions and customization options with you.

Build your RFQ specification

Select the required connector format. This creates an RFQ specification for engineering review; it does not calculate an online price.

Choose pitch and rows to see the supported catalog pin range. Special multi-row or out-of-range designs require drawing review.

Pitch

Rows

Positions per row

Total pin count Calculated automatically

Mounting

Mating pin length

Plastic height

Solder tail length

Plating

Target quantity

Final dimensions, tolerances, plating and packaging are confirmed by drawing, sample or approved specification.

Available product variants2 catalog options

Photo	Code	Professional English Name	Pitch	Rows / Positions	Mounting	Height	Drawing
	0139	3.96mm Female Header Connector, Single Row, 1x2P to 1x20P	3.96mm	Single row / 1x2P to 1x20P	Single Row	Customizable by drawing/sample	Request drawing
Series ref.	By drawing	3.96mm SMT Female Header Connector, Single Row, 1x2P to 1x20P	3.96mm	Single row / 1x2P to 1x20P	SMT, Single Row	Customizable by drawing/sample	Request drawing

Get 2D drawing or send RFQ

Request the drawing for a selected code, or send an RFQ for pricing and customization.

Get 2D drawing RFQ quote

Related RFQ guides

Specification guides for this connector

Match pin header and female header before RFQ Use this guide to check board-to-board fit and mating connector details. Pin header tail length and plastic height RFQ guide Helpful when the mating pin header height or solder tail affects the female header choice. 2.54mm pin header selection guide Reference guide for common mating pin header specification details.

Can Kirision customize the height for this 3.96mm Female Header Connector?

Yes. Plastic height, total height and tail length can be reviewed by drawing or sample for OEM/ODM RFQ projects.

What information is needed for a 3.96mm Female Header Connector quotation?

Send pitch, rows, positions, mounting style, height requirement, drawing or sample photo, quantity and plating requirement.

RFQ quote Get 2D drawing View Female Header series Back to catalog Custom OEM/ODM support

Connector Specification Review

For this connector, confirm pitch, rows, positions, mounting style, orientation, material, plating, packaging and mating connector before sample approval or production quotation.

Pitch	Confirm by drawing
Rows	Single row, dual row or custom
Positions	Custom pin count available
Mounting Style	Through-hole, SMT or right-angle options
Orientation	Straight or right angle
Insulator Material	PBT, PA6T or project-specified insulator
Contact Plating	Tin, gold flash or custom plating
Current Rating	Confirm by specification
Voltage Rating	Confirm by specification
Operating Temperature	Confirm by material and application

Files for Faster Quotation

Send PDF drawing, DWG, STEP, BOM, sample photo, target quantity and application notes. Kirision will review manufacturability, custom options, sample availability, MOQ and lead time.
